Monitor Wedge Speaker

Wedge Speaker
Wedge Speaker
Get A Quote
Features
Technical Specifications

Features of Monitor Wedge Speaker GX-SP1012B-C / GX-SP1015B-C

  • Compact multi-purpose box structure design can be placed horizontally and vertically

  • Adopt customized high-efficiency coaxial technology speaker unit

  • The high/low frequencies have completely overlapping diffusion characteristics

  • Optimized built-in crossover design, abundant sound pressure and comfortable tone

  • Have perfect frequency response, phase response and excellent return ability

  • Black wear-resistant environmentally friendly water-based paint spraying, high-grade elegant appearance

Technical Specifications of Monitor Wedge Speaker GX-SP1012B-C / GX-SP1015B-C

ModelGX-SP1012B-CGX-SP1015B-C
TypePassive two way full range speaker
DriversLF:1×12”; hf:1×1.75”LF:1×15”; HF:1 ×3”
Frequency response68HZ~20KHZ70HZ~18KHZ
Sensitivity(1W/1m)96 dB99dB
Power300W(AKS)/1200W(PEAK)500W(AKS)/2000W(PEAK)
MAX SPL121dB/127dB126dB/132dB
Impedance8Ω
Dispersion60°(H)×40°(V)100 °(H)×100 °(V)
Connector2×NL4MP speakon2 × NL4MP speakon
Product Size(W*D*H)417*336*616mm538 * 375*580mm
Package Size(W*D*H)500*410*690mm615 * 445 * 645mm
Net Weight21.4kg25.9kg
Gross Weight23.6kg28kg
ColorBlack (white can be customized)
HangerFoot nail installation
