How to Choose an HDMI Matrix for a Professional Conference Room

Aug 26-2026

GONSIN Introduces the Video Conferencing Kit


Table of Content [Hide]

    Brand: GONSIN
    Model: Video Conferencing Kit

    GONSIN Video Conferencing Kit – designed for online meetings, negotiations, conferences, and distance learning. It provides high-quality video transmission and clear, intelligible audio communication between conference participants.


    Technical Specifications:

    Video Camera

    • Image sensor: 1/2.8" CMOS, 5 MP
    • Maximum resolution: 1920 × 1080, 60 fps
    • Optical zoom: 20×
    • Focal length: 5.5–110 mm
    • Digital zoom: 10×
    • Field of view: 54.7° to 3.3°
    • Aperture: F1.6–F3.5
    • Minimum illumination: 0.5 lx
    • Signal-to-noise ratio: >55 dB
    • Noise reduction: 2D and 3D DNR
    • Focus: Auto, Manual, One Push
    • White balance: Auto and Manual
    • Backlight compensation: supported
    • Wide Dynamic Range (WDR): adjustable
    • Video outputs: HDMI, 3G-SDI, USB 2.0, LAN
    • Network resolution: up to 1920 × 1080, 60 fps
    • Video codecs: H.265, H.264, MJPEG
    • Network protocols: RTSP, RTMP, ONVIF, GB/T28181
    • Audio input: stereo, 3.5 mm jack
    • Control interfaces: RS-232, RS-485, IP
    • Control protocols: VISCA, Pelco-D, Pelco-P
    • Horizontal pan: ±170°
    • Vertical tilt: −30° to +90°
    • Pan speed: 0.1–100°/s
    • Tilt speed: 0.1–30°/s
    • Preset positions: up to 255
    • Power supply: 12 V DC, 1.5 A
    • Maximum power consumption: 12 W
    • Operating temperature: −5 to +45 °C
    • Dimensions: 258 × 172 × 169 mm
    • Net weight: 1.54 kg
    • Gross weight: 2.3 kg
    • Installation: desktop or wall-mounted with an optional bracket


    Microphone

    • Microphone array: 8 digital microphones
    • Pickup pattern: omnidirectional, 360°
    • Audio pickup range: up to 10 m in diameter
    • Sensitivity: −36 dB ±1 dB
    • Signal-to-noise ratio: 68 dB(A)
    • Maximum sound pressure level: 130 dB
    • Audio processing: automatic gain control, AI-based noise reduction, acoustic echo cancellation, reverberation suppression
    • Built-in speaker: 5 W, 4 Ω
    • Speaker frequency response: 80 Hz – 20 kHz
    • Speaker sound pressure level: 84 ±2 dB, 1 W/0.5 m
    • Total harmonic distortion: ≤3%
    • Interfaces: 2 × RJ45, USB Type-C, DC power input
    • Power supply: 48 V DC, PoE or USB
    • Daisy-chain connection: up to 4 devices via PoE network cable
    • Compatible operating systems: Windows, macOS, Android, Linux
    • Operating temperature: 0 to +45 °C
    • Storage temperature: −20 to +50 °C
    • Dimensions: Ø120 × 70 mm
    • Net weight: 0.43 kg
    • Gross weight: 0.8 kg
    • Installation: desktop; optional tripod or ceiling mounting
