Gonsin Android Paperless Conference System LCD Lifter Demonstration



Basic functions:


microphone

1, passed the IEC 60914 international standard certification;

2. Used in conjunction with the chairman unit connector;

3, the microphone has a function of reducing the automatic return; when the microphone is lowered, the microphone is automatically turned off;

4. The microphone has five speech modes: application waiting, restricted speech, first-in-first-out, voice-activated speech, and application for speech (need to cooperate with software);

5. There is no limit to the number of system chairman and vice-chair units;

6, voice control function: In the voice control mode, the microphone is automatically turned on when the participant speaks; the sensitivity of the voice control (high, medium and low) can be adjusted by the master controller, and the automatic microphone off time (20 to 250 seconds) can be set. Turn on up to 4 microphones at the same time (excluding the chairman unit);

7, electret heart-shaped directional microphone, richer tone;

8, the microphone has superior resistance to mobile phone interference;

9, automatic camera tracking, panoramic preset position, support for extended HD / SD camera tracking system;

10. It can be connected to the voting module and the simultaneous transmission module to realize the function expansion;

11, the system has an automatic repair function, support line "hot swap";

12, with the software, you can control the speaking time according to the meeting situation;



Touch LCD lifter

13, LCD screen, microphone rod independent lifting design, panel buttons individually control LCD screen or microphone rod lifting, flexible use, easy to use, easy to solve equipment hiding, storage problems, keep the venue environment clean;

14. The front screen adopts a 15.6-inch 10-point capacitive touch HD IPS full-view LCD screen with a resolution of 1920×1080 dpi; it is used for paperless system operation;

15, using low-speed micro-motor to drive, strengthen the wire rope transmission, lifting fast and stable, durable wear;

16, quiet design, motor noise is very small during the rise/lower process;

17, the default elevation angle is 15° after the LCD rises, and can be continuously adjusted within the range of 0~30° to ensure the best viewing effect;

18. The lifter panel and the chassis are made of aluminum alloy material, which is light in weight, high in strength and exquisite in craftsmanship;

19, ergonomic, aesthetic design, will not block the line of sight, screen ratio: 16:9 (widescreen);

20, support ten touch, stable and reliable, touch sensitive;

21. The lifter panel has: rise, pause, drop, multimedia conference terminal switch interface;

22, lifter support panel manual control, wireless remote control, RS-232 control, RS-485 control lifter rise, pause, drop and other motion states, can be unified control or group control;

23, the riser panel preset USB interface, support document data import and export;

24, with HDMI, VGA connection, automatic signal recognition switching, can be switched through the panel buttons;

25, electronic table card function: the rear screen is equipped with 11.6-inch 1366×768 high-resolution LCD screen, 16:9 display ratio, high-brightness full-view design, providing high-quality image display function;

26, can display the participant information synchronously, including the participant's name/title / unit name/unit LOGO, etc., support font/background / template custom editing;
